在設計開發電動汽車的過程中，采用實時數字仿真可實現并行工程，縮短開發時間，節約開發費用。基于方框圖建模工具Simulink 建立無刷直流電機驅動系統模型，采用dSPACE 實時仿真環境自動生成控制器及被控對象模型實時代碼。實時仿真系統具有與實際系統的硬件接口，可以與實際控制器或電機系統直接相連，構成硬件在回路仿真測試或快速控制原型系統。實時仿真與真實系統實驗結果表明，實時仿真器與實際系統的響應特性無明顯差別，在開發和測試階段可以代替實際電機系統進行實時閉環測試。
Abstract：In order to reduce cost, risk and development time, the real-time simulator of electric vehicle system can be used
for concurrent engineering. An implementation of the real-time model of brushless DC motor drive for the electric vehicle
based on block-oriented programming tool Simulink is proposed. Also, by using dSPACE environment，the real-time code
of controller and inverter-motor-sensor model is directly generated. Having the real-time hardware interface to actual
system, the real-time simulation system can be directly connected to actual controller or real inverter-motor-sensor system
for hardware-in-the-loop simulation test as well as for rapid control prototyping applications. Experimental results show
that there is no remarkable difference between the responses of the real system and the real-time model, so the real-time
simulation system can replace the real system in the development and test stages.
