function?M?=?animateopt（?toptxoptuoptthetaoptbetaNrho?）
%ANIMATEOPT?animate?the?optimal?state?trajectory
[toptu?idx]?=?unique（topt）;
xoptu?=?xopt（idx:）;?%unique（xopt‘rows‘）;
uoptu?=?uopt（idx）;
thetaoptu?=?thetaopt（idx）;?%?remove?duplicate?values
t?=?0:0.1:6;
xoi?=?interp1（toptuxoptut）;
uoi?=?interp1（toptuuoptut）;?%?trust?$u$
haoi?=?atan（xoi（:4）./xoi（:3））;?%?heading?angle
haoi（1）?=?haoi（2）;
toi?=?interp1（toptuthetaoptut）;?%?trust?angle?$\theta$
[xy]?=?meshgrid（-1:0.5:5）;
fx?=?（beta*（3-x））./（（y.^2+（x-3）.^2）.^（3/2））;
fy?=?（-beta*y）./（（y.^2+（x-3）.^2）.^（3/2））;
figure;
for?k=1:length（t）
????%?contruct?the?shape?of?a?boat?around?the?point?with?respect?to?
????%?heading?angle
????bx=?xoi（k1）+?[0.2*cos（haoi（k）-0.5）?0.3*cos（haoi（k））?...
????????0.2*cos（haoi（k）+0.5）?0.2*cos（haoi（k）-0.5）?...
????????-0.2*cos（haoi（k）+0.5）?-0.3*cos（haoi（k））?...
????????-0.2*cos（haoi（k）-0.5）?-0.2*cos（haoi（k）+0.5）?...
????????-0.2*cos（haoi（k）-0.5）?0.2*cos（haoi（k）+0.5）];
????by=?xoi（k2）+?[0.2*sin（haoi（k）-0.5）?0.3*sin（haoi（k））?...
????????0.2*sin（haoi（k）+0.5）?0.2*sin（haoi（k）-0.5）?...
????????-0.2*sin（haoi（k）+0.5）?-0.3*sin（haoi（k））?...
????????-0.2*sin（haoi（k）-0.5）?-0.2*sin（haoi（k）+0.5）?...
????????-0.2*sin（haoi（k）-0.5）?0.2*sin（haoi（k）+0.5）];
????plot（xoi（1:k1）xoi（1:k2）‘b-‘bxby‘b-‘[0?3?4][0?0?4]‘ko‘...
????[xoi（k1）xoi（k1）+uoi（k）/max（abs（uoptu））*cos（toi（k））]...
????????[xoi（k2）xoi（k2）+uoi（k）/max（abs（uoptu））*sin（toi（k））]...
????????‘r:‘‘LineWidth‘2）;?%?using?red?dotted?line?to?denote?direction?of
????%?the?trust?and?its?length?is?proportional?to?the?control?effort?$u$
????hold?on;quiver（xyfxfy1‘LineWidth‘2‘Color‘‘black‘）;hold?off
????xlabel（‘x_1（t）‘‘fontsize‘14）
????ylabel（‘x_2（t）‘‘fontsize‘14）
????set（gca‘FontSize‘12）
????title（[‘\beta=‘int2str（beta）‘?N=‘int2str（N）‘?\rho=‘int2str（rho）]）
????xlim（[-1?5]）;ylim（[-1?5]）;
????axis?square;
????M（k）?=?getframe（gcf）;
end
end
